Andatech Soberpoint 3 Wall-Mounted Public Breathalyser

Free standard shipping for orders over $500

Andatech Soberpoint 3 Wall-Mounted Breathalyser

Request a quote

AS3547

Australian Standard certified

6 months

Calibration frequency

Description

Durable, easy-to-use wall mounted breathalyser. Simply blow through a drinking straw to take a test. Coin & wave payment options available.

Specifications

  • Sensor type
    Replaceable Fuel Cell Sensor
  • Testing mode
    Specific testing
  • Accuracy
    ±0.005%BAC at 0.100%BAC
  • Response time
    Within 6 seconds
  • Recovery time
    10 seconds
  • Calibration frequency
    Unlimited tests, every 6 months
  • Display
    LCD screen
  • Power supply
    AC: 110-240V 50-60Hz, 1A input / DC: 12V, 3A output
  • Weight
    3500g including batteries
  • Dimensions
    H: 330mm, W: 255mm, D: 90mm
  • Warranty

    3 years, extendable up to 8 years (on the sensor) under the Andatech Guarantee

  • Includes
    Includes Andatech Soberpoint 3, power cable, user manual.

Downloads

Convenient breath alcohol test for everyone

Wall mounted breathalyser for breath alcohol testing at building entrances and public spaces. Just push a button and blow through a straw.

Andatech Soberpoint 3 Breathalyser Features
  • Accurate and reliable

    Accurate & reliable

    Accuracy of ±0.005 %BAC at 0.100 %BAC. Australian Standard AS3547:1997 certified.

  • Fast icon

    Fast specific tests

    Response time of 6 seconds and recovery time of 10 seconds before the next test.

  • ads icon

    Announcement / promotion display

    Besides showing instructions for breath alcohol testing, the LCD screen can be used to display announcements.

  • money bag icon

    Monetisation potential

    Optional pay-per-test feature by accepting coins or cashless payment for each breath alcohol test.

  • exchange icon

    No calibration downtime

    Replaceable sensor allows the breathalyser to function when one is sent for calibration.

Breath alcohol testing with a potential for monetisation

Pay-per-test features that are suitable for income generation at hotels, restaurants, pubs, bars, and other licensed venues.

  • Andatech Soberpoint 3 Coin

    Andatech Soberpoint 3 Coin

    Accepts $1 and $2 coins. You can decide the cost for each test.

  • Andatech Soberpoint 3 Wave

    Andatech Soberpoint 3 Wave

    Allows cashless payment with credit card, debit card, or payWave.

How to use the Andatech Soberpoint 3 Wall-Mounted Breathalyser

  • How to use the Andatech Soberpoint - step 1

    1. Press the button located on the side of Soberpoint 3 (or make a payment if using the Soberpoint 3 Coin or Wave versions)

  • How to use the Andatech Soberpoint - step 2

    2. Insert a straw and follow the instructions on screen.

  • How to use the Andatech Soberpoint - step 3

    3. The BAC test result will be displayed on the screen together with low, warning, or danger indication.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Compare Andatech Breathalysers

View and compare all bestselling Andatech workplace breathalysers below

A table comparing the facets of 3 products
Facet
Andatech Soberpoint 3 Lite wall mounted breathalyser
Andatech Soberpoint 3 Wall-Mounted Breathalyser
Andatech Soberlive FRX breathalyser with facial recognition and temperature screening
Andatech Soberlive FRX Wall-Mounted Breathalyser
Andatech AccessPoint wall mounted breathalyser with access control
Andatech AccessPoint Wall-Mounted Breathalyser
Price
Price
Get a quote
Get a quote
$1,350
Summary
Summary
Public use breathalyser. Coin & wave payment options
Facial recognition, RFID access. Andalink compatible
For access control. No mouthpiece required
Certification
Certification
Certified to AS 3547:1997
Certified to AS 3547:2019
-
Calibration Frequency
Calibration Frequency
Unlimited tests, every 6 months
Unlimited tests, every 12 months
Unlimited tests, every 12 months
Memory
Memory
-
10,000 registered faces, 20,000 test results. Sync data with Andalink.
-
Accuracy
Accuracy
±0.005%BAC at 0.100%BAC
±0.005g/210L for readings up to 0.100g/210L
±0.005%BAC at 0.050%BAC
Testing Mode
Testing Mode
Specific testing
Specific testing, Passive testing
Passive testing
Response Time
Response Time
Within 6 seconds
Within 5 seconds
3 seconds
Recovery Time
Recovery Time
10 seconds
1 second / 20-30 seconds for facial recognition and temperature screening
5 seconds
Display
Display
LCD screen
LCD screen
-
Connectivity
Connectivity
-
Ethernet, Wi-Fi, 4G (optional)
-
Features
Features
-
Andalink, Photo verification
-
Power Supply
Power Supply
AC: 110-240V 50-60Hz, 1A input / DC: 12V, 3A output
AC: 100-240V 50-60Hz / DC: 12V 3A
12V / 1.5A (power adaptor not supplied)
Weight
Weight
3500g including batteries
1243g including batteries
674g
Dimensions
Dimensions
H: 330mm, W: 255mm, D: 90mm
H: 220mm, W: 200mm, D: 88mm
H: 20.6cm, W: 10.8cm, D: 3.7cm
Warranty
Warranty

3 years, extendable up to 8 years (on the sensor) under the Andatech Guarantee

3 years, extendable up to 8 years (on the sensor) under the Andatech Guarantee

3 years, extendable up to 8 years (on the sensor) under the Andatech Guarantee

Includes
Includes
Includes Andatech Soberpoint 3, power cable, user manual.

Includes Andatech Soberlive FRX, power cable, RS232 cable, user manual, 2 straw adaptors, 5 sampling cups, 2 keys (unlock to connect to bracket), 2 screws, 2 wall plugs.
Includes Andatech AccessPoint, user manual, brackets, connecting cable including power switch, dust cover for sampling port, screws for assembly.
