Andatech Prodigy 2S / 2S Lite user manual

Thank you for purchasing the Andatech® Prodigy 2S / 2S Lite breathalyser.

The Andatech® Prodigy 2S is a state-of-the-art instrument used to detect ethyl alcohol from a valid breath sample. It uses an electrochemical fuel cell to measure the concentration of alcohol in the breath sample expelled from a human subject.

If alcohol is present, a corresponding voltage is generated from the fuel cell, which is proportional to the alcohol content of the sample provided by the human subject. This voltage is then sent to the CPU and converted to the subject’s BAC (blood alcohol concentration) which is then displayed.

Operator needs to read operation manual and familiar with the operation before using. Retain the manual for future reference.

View and download the Andatech Prodigy 2S/Lite breathalyser user manual [PDF].

---

Preparation

Use coin or a similar object to twist the lock anticlockwise to unlock the battery compartment. Gently open the battery compartment cover to remove it. Insert battery. Replace the battery compartment cover and lock the compartment by twisting it clockwise.

Device features

Diagram explanation

1. Disposable mouthpiece

Each mouthpiece is individually packed and sealed for hygiene reasons. Before each new Standard Test, attach a new mouthpiece to the sample port to prevent contamination from a previous test.

2. Sampling cup

The sampling cup can be used for Screening Tests and is reusable as long as no alcohol is detected in the previous test. Each sampling cup is also individually sealed. Attach a sampling cup to the sample port to take a passive test. Do not allow the mouth to touch the sampling cup during testing. After use, remove the sampling cup and clean it with alcohol or boiling water. Allow it to dry completely before re-using it.

3. Button to remove mouthpiece

The mouthpiece can be removed from the breathalyser hygienically by pushing this button up. This will eject the mouthpiece for easy disposal without touching the mouthpiece.

4. Touch screen display

This displays the instructions and the alcohol concentration reading of breath tests taken on the unit. Select the icons and buttons on the screen using the stylus pen provided.

5. On/Off button

Press and hold the On/Off button to turn the device on or off.

6. Battery charging

The battery can be charged while inside the device. The battery charging indicator turns red when the battery is charging, and green when the battery is fully charged.

7. External power connectors

Connectors for 12V car (cigarette) adapter or optional 12V power transformer. The battery can be charged while inside the device.

8. USB connector

Use a USB cable to upload test records stored in the internal memory and upgrade the software.

Screen Display



Conditions for testing

Measurements & conditions for test

• Use a clean mouthpiece for each test.
• The optimum temperature range for operating the unit is -10°C to 50°C. Use within this temperature range will limit condensation from the subject’s breath and ensure an accurate reading is taken.
• Do not allow samples containing smoke, tobacco or other chemical products to enter the unit, as damage to the fuel cell can occur.
• It is recommended that the operator observes the subject for approximately 20 minutes before administering the breath test. This is to ensure the subject does not consume anything. Following this procedure will ensure the subject’s saliva is clear of alcohol so that it does not alter the outcome of the breath sample test.
• There must be an interval of at least 15 minutes after alcohol consumption as alcohol residue in the mouth may give a false reading. Such residue may also be left by aromatic drinks, mouthwash, medicines and drops, as well as by belching and vomiting. Mouth rinsing with water or non-alcoholic drinks does not substitute for an interval.
• A person’s blood alcohol concentration (BAC) can continue to rise for up to 2 hours after drinking alcohol. If a result is close to the designated BAC, it is recommended to wait and retest after 20 minutes.
• It can take 10 hours or more for a person’s BAC to return to zero after a high BAC has been reached. A further test should be carried out later in the day or the following morning.

Operating instructions

Attaching a sampling cup

1. Tear the perforated section from the wrapper of a new sampling cup.
2. Pull back the wrapper to expose the bottom half of the sampling cup.
3. Ensuring the two small holes in the bottom of the sampling cup are aligned with the sensor, insert the notched end of the sampling cup into the slot on the right of the screen.
4. Lower the other end of the sampling cup until it locks into place.
5. Remove remainder of wrapper from sampling cup and discard.
6. To discard the sampling cup, pull it out in the direction of the arrow shown on the sampling cup.

Attaching a mouthpiece

1. Tear the perforated section from the wrapper of a new mouthpiece.
2. Pull back the wrapper to expose half the mouthpiece.
3. Ensuring the two small holes in the bottom of the mouthpiece are aligned with the sensor, insert the notched end of the mouthpiece into the slot on the right of the screen (refer to Image 1).
4. Lower the other end of the mouthpiece until it snaps into place (refer to image 2).
5. Remove remainder of wrapper from mouthpiece and discard.
6. To discard the mouthpiece after a test, slide the remove mouthpiece button upwards (refer to image 3). This will eject the mouthpiece from the unit.
7. Use a new mouthpiece for each test.

Before taking a test

Refer to "Conditions for Testing" before conducting a Screening or Standard Test.

Screening test

1. Attach a sampling cup onto the sample port and select the Screening Test button.
2. When the screen displays “Please Blow”, take a deep breath and blow into the sampling cup until the BEEP tone stops.
3. An “Alcohol Detected” or “No Alcohol” result will display on the screen.
4. If the screen shows “Alcohol Detected”, use a mouthpiece to perform a Standard Test to obtain a specific alcohol reading.
5. The operator can get an immediate Screening Test result by pressing the "Manual" button while the subject is still blowing.
6. Select the Repeat Test button to start another test.

NOTE: A Screening Test only checks for the presence of alcohol in a breath sample. An accurate test result can only be obtained via a Standard Test using a mouthpiece.

NOTE: Test records of Screening Tests cannot be printed or stored.

Standard test with input

1. Attach a mouthpiece onto the sample port and select the Standard Test button.
2. The breathalyser will take an Air Blank Test to ensure the mouthpiece and sensor are clear of alcohol from previous tests.
3. If the Air Blank Test result shows 0.000, the unit will proceed to test mode (skip the step 5).
4. If alcohol is detected, verify that a clean mouthpiece is being used and select "RETEST".
5. Use the stylus pen to input information. NOTE: Maximum 16 characters for each input.
   Use the left or right arrow buttons to move to the previous or next field. If no data fields are selected, the unit will proceed directly to test mode. (Contact Andatech to enable/disable data fields)
6. When the screen displays “Please Blow”, take a deep breath and blow into the mouthpiece with a slow and steady breath until the BEEP tone stops.
7. The test result will display on the screen.
8. Select the Print button to print the test result*.
9. Select the Repeat Test button to take another test.
10. If the subject does not blow into the unit within 30 seconds, the operator can either select “Refuse” to confirm the subject refused to take the test, or “Test Again” to allow the subject to retry.
11. If the subject stops blowing too early or blows with insufficient force, select “Discontinue” to abandon the test, or “Test Again” to retry.
12. The operator can also get an immediate Screening Test result by pressing the “Manual” button while the subject is still blowing.
13. Push the button underneath the mouthpiece to remove the mouthpiece and take another test.

*All print functions are applicable to the Prodigy 2S only.

Test records

Searching test records

1. Select Test Records from the homescreen and then select "Search".
2. Select one of the following methods to search:
• Record No.
  Search format: enter the 5-digit record number
• Date
  Search format: 8 digits (YYYYMMDD), e.g. 31 December 2023 is 20231231.
• Test Mode
  From the drop down menu, select “Auto”, “Manual”, Discontinued” or “Reject”.
• Test Result
  From the drop down menu, select "> 0" to search for positive test results or "= 0" for 0.000 test results.
3. Select the right arrow button to confirm and search. A list of the test record numbers that fulfill your search criteria will be shown.
4. Use the left arrow and right arrow buttons to scroll through multiple pages of the search results.
5. Select the test record number to view the test record.

Printing test records*

Records can be printed from the Test Result screen and Test Record screen for Standard Tests only.

Screening Test results cannot be printed.

1. Select the Print button on the test result or test record screen to print.
2. Use the left arrow or right arrow buttons to move to the previous or next record.

Test records memory and upload

Up to 65,000 test records can be stored, depending on the length of the records.

Once the memory is full, you will not be able to take another test.

It is recommended to upload device records using “Andalink” software on a regular basis to prevent loss of records.

After uploading records, the device memory can be cleared.

In order to download your data to a PC you must have the Andalink for Prodigy 2S software, available from www.andatech.com.au

Settings

Auto off

• Select the time limit to turn off the device automatically.
• Select the right arrow button to confirm.

Auto print*

• Select “Auto Print” to print results automatically after each test is completed.
• Select the number of printout copies required for test results that have zero alcohol reading ( = 0 ) and for test results that have a positive alcohol reading ( > 0 ).
• Select the right arrow button to confirm.

NOTE: If no printout is needed for zero alcohol test results, select “0” for the field “=0”.

*All print functions are applicable to the Prodigy 2S only.

Cal.

Only authorised personnel have access to these settings.

Brightness

Adjust the brightness level of screen.

GPS

• The Longitude and Latitude of the device's location will be shown.
• The Longitude and Latitude of the test is stored and printed on the printout.
• Uncheck the “Print GPS”* tickbox to disable printing the Longitude and Latitude on test records.
• Select the right arrow button to confirm.

NOTE: GPS system only functions for 5 to 10 minutes after the device is switched on. Use the device in an open area so that it can receive the GPS signal. If there is no GPS signal, the Longitude and Latitude will not be shown on the printout.

Date and time

• Set the correct Date and Time.
• Select “Update” to confirm.

Advanced settings

Only authorised personnel have access to advanced settings.

Keyboard

Deselect “Keyboard” to disable the keyboard.

NOTE: Keyboard cannot be disabled if data entry is set compulsory in advanced settings.

Touch screen calibration

If the touch screen is not sensitive enough or not responding, please calibrate the screen.

1. While the device is switched off, press and hold the On/Off button (right button) and then press the Function button (left button) immediately after.
2. Follow the instructions on the screen to calibrate the screen.

Printer

The Prodigy 2S features a built-in thermal printer.

Insert / replace paper

Pull the handle. When inserting a new roll of paper, make sure the glossy/outer side of the paper is facing the serrated tear strip once the door is closed.

NOTE: If nothing can be printed, change the orientation of the paper roll and try again.

Standard thermal paper size

57 x 24 mm

See: Thermal Paper Roll for Andatech Device Printers to purchase more

Battery charging

The Prodigy 2S uses a high capacity lithium battery. It is located behind the sliding cover on the back of the device.

The battery power level is indicated on the Prodigy 2S’s display screen.

When the battery power is low, connect the charging cable to the charging port to charge the battery. The included cigarette plug adaptor can also be used for charging.

The charging indicator light will turn from red to green when the battery is fully charged.

1. Connect the charging cable to charging port to charge the battery.
2. Charging indicator turns from red to green when the battery is fully charged.

Troubleshooting

'CALIBRATION NEEDED' WARNING

When the device starts up and shows the "Calibration Needed" warning and alarm, it means the device has passed its calibration due date.

Contact an authorised calibration centre to get the device calibrated.

TOUCH SCREEN NOT RESPONDING

If the touchscreen is not sensitive enough or not responding, calibrate the screen.

Follow the instructions for ‘Touch Screen Calibration’ above.

AIR BLANK TEST CONTINUES TO DETECT ALCOHOL

Let the device sit for 5 minutes to clear out any possible residue.

If the problem persists, contact Andatech.

Disclaimers

• This product must be used strictly in accordance with the instructions in this manual.
• This product is intended to provide the user with an indication of alcohol on the breath. However, neither the manufacturer nor the supplier gives any warranty (express or implied) that the product can give any indication of blood alcohol level.
• A person's BAC (Blood Alcohol Concentration) can only be accurately measured by the administration of a blood test. This product only measures breath alcohol content which, in turn, only gives an approximate indication of blood alcohol concentration.
• In these circumstances the user of this product should not rely on the information provided thereby as an accurate indication of their blood alcohol concentration or of their level of intoxication or of their fitness to drive and in particular should not take any action in reliance on such information as the product can provide no more than an indication of alcohol on the breath.
• If the user of this product makes any decision or takes any action based on the use of the product such decision or such action shall be at the sole risk of the user and neither the manufacturer nor the supplier assumes any responsibility for such decision or action.
• In particular, neither the manufacturer nor the supplier shall be in any way liable if the user of the product asserts that the product led them to believe they were fit to operate a motor vehicle and are subsequently found not to be so fit.
• If the subject fails to give a valid breath sample, the operator can either select “Discontinue” to confirm; or can select “Test Again” to allow the subject to re-test. A passive test can be performed by selecting “Passive” whilst the user is blowing. Slide up the button underneath the mouthpiece to remove the mouthpiece.

Things to remember

• Always wait a minimum of 15 minutes after your last drink before testing.
• NEVER take a sip of alcohol and blow immediately into the device.
• Ignoring these two points WILL cause damage to the unit that is NOT covered by warranty.

Recalibration and service

Andatech recommends the Andatech® Prodigy 2S / 2S Lite be calibrated every 6 months (unlimited tests) to maintain Australian Standards.

For recalibration and technical support, please go to my.andatech.com.au or contact Andatech support.

For more information, visit andatech.com.au/calibration
