Andatech Surety user manual - Andatech

Andatech Surety user manual

Thank you for purchasing an Andatech Surety breathalyser

The operator of this device should read the operation manual and be familiar with the device operation before using it. Retain the manual for future reference.

View and download the Andatech Surety breathalyser user manual [PDF].


Components

Andatech Surety breathalyser components

  1. Lamp
  2. IrDA window
  3. Display
  4. Up button
  5. Menu, down button
  6. Power, select button
  7. Battery cover release
  8. Battery cover
  9. Sensor
  10. Batteries
  11. USB/printer connector
  12. Hand strap
  13. Mouthpiece receptacle
  14. Mouthpiece
  15. Sampling cup for fast mode
  16. SD card slot

Contents

1 x Breathalyser

5 x Mouthpiece

1 x Hand strap

1 x USB cable for PC

2 x Batteries

1 x Manual

1 x Leather pouch

1 x Sampling cup for fast mode

[Sold separately] Printer, Bluetooth, SD card

Preparation

Attaching the hand strap

Attach hand strap onto Andatech Surety breathalyser

Slide the battery cover release to the right and push the battery cover downwards to remove it.

Insert hand strap into the small hole in the housing. Loop it around the hook on the inside of the hole, then replace battery cover.

Fitting the mouthpiece or sampling cup

Fitting mouthpiece on to Andatech Surety breathalyser

Insert mouthpiece into the port on the top of the device securely with
a click.

*The same applies to the sampling cup for fast mode.

Basic operation

How to use the Andatech Surety breathalyser
  1. Press the power button to switch on the unit.
    Note: You can press and hold down the power button (when device is switched off) to see the device information including serial number, date and time.
  2. The unit will start to warm up. Install a mouthpiece onto the breathalyser.
  3. When "BLOW" is displayed, blow slowly and steadily through the mouthpiece until the tone stops.
  4. "Analyzing / Wait" is displayed while the breath sample is being processed.
  5. The test results will be displayed for 15 seconds.
    If a printer is connected, a test receipt will print.

Taking consecutive tests

  • The unit will display the results for 15 seconds and then turn off.
  • To take a consecutive test, press the power button once after the result is displayed on the screen.
  • Wait for “BLOW” to be displayed before taking another test.

Powering the unit off

  1. Press and hold the power button.
  2. "Power off" will be displayed.
  3. Continue holding the power button until the unit is powered off (approximately 3 seconds).

Auto power off

  • If no activity is detected for 4 minutes the unit will automatically switch off to save on battery life.
  • If the printer cable is connected or the unit is in “Fast” mode, Auto Off time is extended to 15 minutes.

Downloading data

Test results are saved onto the device. Results can be downloaded to your PC via the Andatech Surety software.

To download Andatech Surety software, go to andatech.com.au/surety-software

Fast mode operation

Fast Mode checks for the presence of alcohol in a breath test, and provides a fast Pass/Fail response. Individual mouthpieces are not needed; just use the sampling cup. Set the measurement mode to “Fast mode” in the menu to enable fast testing. Refer to page 12 of the Surety manual (PDF) on Measurement mode.

Andatech Surety breathalyser fast mode operation
  1. Turn the unit on.
  2. Wait for the unit to display “Blow”, an “F” will display in the upper right corner to indicate unit is in fast mode.
  3. Blow into the sample cup until the unit beeps.
  4. Results will display as “Pass” or “Fail”.
  5. If a printer is connected, a test result will print.
  6. When “BLOW” is displayed, subsequent tests can be performed.

Taking a standard test while in Fast mode

While in "Fast mode", a standard test can be taken as follows:

Andatech Surety breathalyser change modes

  1. When the unit displays “BLOW”, press the [UP] button to cycle between Fast and Normal mode.
    On the upper right corner of the Surety display screen, "F" will change to "N" to indicate the unit has changed from Fast mode to Normal (standard test) mode.
    (“F”= Fast Mode, “N” = Normal Mode)
  2. Unit will return to fast mode automatically after the test in normal mode.

Troubleshooting / warning display

Flow error

Flow error during test. Breath sample was not steady enough or it was not long enough. Wait for the device to return to ready condition. Blow with a long steady breath. Continue blowing until tone stops.

OLT

The maximum result that can be displayed by the device is 0.300 g/210L.

If the test result exceeds 0.300 g/210L, the device will display “OLT” on the screen.

Andatech Surety breathalyser battery

Battery power is low. Please replace the batteries.

Calibration required

Calibration service is required. Please contact Andatech support to get your breathalyser calibrated.

C. Test no

Number of tests after calibration (Memorised in sensor module)

L. Test No

Number of tests with device (Memorised in device)

Sensor error - Ensure Sensor Correctly Installed

Error with sensor module - Contact Andatech support for assistance.

Over Temperature - Observe Operating Temperature Range

Error with operating temperature.

The device is only functional between -5°C and 40°C. Please ensure these temperature conditions are met when operating the device.

System Error 1 - Service required

Condenser charging error. Contact Andatech for support.

System Error 2 - Service required

Sensor leakage issue. Contact Andatech for support.

Print Cable Not Connected

If there is no cable connection, LCD will display “Print Cable not Connected”.

Menu & printer function

Please refer to page 10 of the Andatech Surety breathalyser user manual [PDF] for detailed instructions.

See: Thermal Paper Roll for Andatech Device Printers to purchase more thermal paper rolls.

Replacing batteries

Replacing the batteries on the Andatech Surety breathalyser

  1. Slide battery cover release to the right (1) and slide the cover (2) downwards to remove it.
  2. Remove the batteries and replace with new ones.
  3. Slide battery cover back up and lock it into place.

Note: This device uses alkaline batteries only. Please remove the batteries if the device is not used in a long time.

Measurements & Conditions for Test

  • The optimum conditions for the Andatech Surety are:
    Working temperature range: -5°C to 40°C
    Storage temperature range: -10°C to 50°C
  • Do not store in an extreme environment where high temperature or high humidity exists. Keep out of the reach of children.
  • Use the instrument within its optimum working temperature range to limit condensation from the subject’s breath and ensure an accurate reading is taken.
  • Use a clean mouthpiece for each test.
  • Do not allow samples containing smoke, tobacco or other chemical products to enter the instrument, as damage to the fuel cell can occur.
  • It is recommended that the operator observes the subject for approximately 20 minutes before administering the breath test. This is to ensure the subject does not consume anything. Following this procedure will ensure the subject’s saliva is clear of alcohol so that it does not alter the outcome of the breath sample test.
  • There must be an interval of at least 15 minutes after alcohol consumption as alcohol residue in the mouth may give a false reading. Such residue may also be left by aromatic drinks, mouthwash, medicines and drops, as well as by belching and vomiting. Mouth rinsing with water or non-alcoholic drinks does not substitute for an interval.
  • A person’s blood alcohol concentration (BAC) can continue to rise for up to 2 hours after drinking alcohol. If a caution results or a result is close to the designated BAC, it is recommended to wait and retest after 20 minutes.
  • It can take 10 hours or more for a person’s BAC to return to zero after a high BAC has been reached. A further test should be carried out later in the day or the following morning.

Liability for proper function or damage

The liability for proper functioning of the instrument is irrevocably transferred to the owner or operator in the event the instrument is serviced or repaired by personnel not employed or authorised by Andatech. In such an event, the warranty will be void.

Disclaimers

  • This product must be used strictly in accordance with the instructions in this manual.
  • This product is intended to provide the user with an indication of alcohol on the breath. However, neither the manufacturer nor the supplier gives any warranty (express or implied) that the product can give any indication of blood alcohol level.
  • A person’s BAC (Blood Alcohol Concentration) can only be accurately measured by the administration of a blood test. This product only measures breath alcohol content which, in turn, only gives an approximate indication of blood alcohol concentration.
  • In these circumstances the user of this product should not rely on the information provided thereby as an accurate indication of his blood alcohol concentration or of his level of intoxication or of his fitness to drive and in particular should not take any action in reliance on such information as the product can provide no more than an indication of alcohol on the breath.
  • If the user of this product makes any decision or takes any action based on the use of the product such decision or such action shall be at the sole risk of the user and neither the manufacturer nor the supplier assumes any responsibility for such decision or action. In particular, neither the manufacturer nor the supplier shall be in any way liable if the user of the product asserts that the product led him to believe that he was fit to operate a motor vehicle and is subsequently found not to be so fit.
  • In particular, neither the manufacturer nor the supplier shall be in any way liable if the user of the product asserts that the product led them to believe they were fit to operate a motor vehicle and are subsequently found not to be so fit.

Things to remember

  1. Always wait a minimum of 15 minutes after your last drink before testing.
  2. NEVER take a sip of alcohol and blow immediately into the device.
  3. Ignoring these two points WILL cause damage to the unit that is NOT covered by warranty.

Recalibration and service

The Andatech® Surety must be calibrated every 12 months to maintain Australian Standards.

For recalibration and technical support, please go to my.andatech.com.au or contact Andatech support.

For more information, visit andatech.com.au/calibration

Andatech Guarantee

Calibrate your breathalyser every 6 months from the date of purchase and extend the manufacturer’s warranty.
Learn more about the Andatech Guarantee.
